Description
4-inch (118mm) durable Direct Thermal or Thermal Transfer label and barcode printer
Compact clamshell design
Offering data processing and print speed up to 5 ips (127mm/sec) to produce high quality 203dpi text, graphics and barcodes
Providing 64MB SDRAM, 125MB Flash Memory
Optional field installable Peeler and external paper supply
Flexible core ribbon handling for half-inch and 1-inch options (74m and 300m)
Media roll diameter up to 127mm
Toolless maintenance of roller and print head
Fully compatible with market-leading programming languages for easy migration
Supporting stand-alone configuration mode by visual LED
Compatible with SLCS™ (BIXOLON) as well as BPL-Z™ (ZPLII), BPL-E™ (EPL) programming languages
Smart switch programming languages without setting the mode
Compatible with label design software including BIXOLON’s Label Artist™-II and Seagull’s BarTender® UltraLite for BIXOLON
Energy Star Certified
Specification
| Print Method | XD3-40d : Direct Thermal , XD3-40t : Thermal Transfer or Direct Thermal |
| Print Speed | Up to 5 ips (127 mm/sec) |
| Print Resolution | 203 dpi |
| Print Width | Up to 104 mm |
| Print Length | Up to 1,000 mm |
| Sensor | Transmissive(Fixed), Reflective(Adjustable), Ribbon-End (XD3-40t), Head Open |
| Media Type | Gap, Black Mark, Notch, Continuous, Fan-Fold |
| Media Width | 15 ~ 118 mm |
| Media Roll Diameter | Up to 127 mm |
| Media Thickness | 0.06 ~ 0.20 mm |
| Supply Method | Easy Paper Loading |
| Inner Core | 25.4 ~ 38.1mm |
| Ribbon Type | Wax, Wax / Resin, Resin, Outside |
| Ribbon Width | 33 ~ 110mm |
| Ribbon Length | Up to 300m |
| Core Inner Diameter | 25.4 mm, 12.7 mm |
| Basic Functions | – Printing speeds of up to 5ips (127mm/sec) – Fully compatible with market-leading programming languages – Simple to set up through a single LED – Smart switch programming languages without setting the mode |
| Dimensions (WxDxH) | XD3-40d : 181 x 222 x 168 mm (7.13 x 8.74 x 6.62 inch) XD3-40t : 210 x 284 x 186 mm (8.3 x 11.2 x 7.3 inch) |
| Weight | XD3-40d : 1.7kg (3.75 lbs.) XD3-40t : 2.6kg (5.73 Ibs.) |
| Electrical | EnergyStar Certified, External Power Adaptor 100-240V AC, 50/60Hz |
| Memory | 64 MB SDRAM, 128 MB Flash |
| Interface | Standard: USB Optional: USB + Serial + Ethernet |
| Real Time Clock | Not Supported |
| Temperature | Operating: XD3-40d: 0 ~ 40℃ (32 ~ 104℉) XD3-40t: 5 ~ 40℃ (41 ~ 104℉) Storage: -20 ~ 60℃ (-4 ~ 140℉) |
| Emulation | SLCS™, BPL-Z™ (ZPLII), BPL-E™ (EPL) |
| Driver / Utility | Windows Driver (Europlus / Seagull) Linux / Mac CUPS Driver Virtual COM USB / Ethernet Driver Utility Program OPOS Driver |
| Connectivity Options | – Standard: USB – Optional: USB + Serial + Ethernet -Bartender Ultralite for BIXOLON Label Artist-II™ |
| SDK / Plugin | Windows SDK, Linux SDK |
| Fonts | Bitmap Fonts (SLCS , BPL-Z, BPL-E) / Scalable Fonts (SLCS, BPL-Z) / Unicode supported (UTF-8, UTF-16LE, UTF-16BE) |
| Graphics | Supporting user-defined fonts, graphics, formats and logos |
| Barcode Symbologies | 1D: Codabar, Code 11, Code 39, Code 93, Code 128, EAN-13, EAN-8, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Plessey, Postnet, GS1 DataBar (RSS-14), Standard 2-of-5, UPC/EAN extensions, UPC-A, UPC-E, IMB 2D: Aztec, Codablock, Code49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code, TLC39 |
| Standard | Cable-USB |
| Options | Peeler, External Paper Supply |
| User-Friendly Design | – Easy paper loading with adjustable paper guide and holder – Easy set up media sensor – Optional peeler and external paper supply – Toolless maintenance of roller and print head – Suitable for both half-inch and full-inch core ribbon (74m and 300m) |
