| Video |
| Image Sensor |
1/2.8” CMOS |
| Max Resolution |
1920x1080 |
| Effective Pixels |
2.0MP |
| Compression Standard |
H.265 / H.264 |
| Maximum Frame Rate |
up to 30 fps |
| Illumination |
0Lux (IR ON) |
| SNR |
52.7dB |
| Lens & IR |
| Lens |
4mm |
| Viewing Angle |
H: 90.6° V: 49.2° D: 107.4° |
| IR-LEDs |
4 IR Array LEDs |
| IR-Distance |
Up to 40 Meters |
| Functions |
| Motion Detection |
Support |
| Email Alert |
Support |
| Day& Night |
Support |
| Starlight |
Support |
| Digital WDR |
Support |
| DHCP |
Support |
| Exposure Control |
Auto |
| Corridor Mode |
Support |
| Auto Gain Control |
Support |
| 3D Noise Reduction |
Support |
| Privacy Mask |
Support up 8 areas |
| Exposure Control |
Auto |
| Image Adjustment |
Support |
| Auto. White Balance |
Support |
| Smart Defog |
Support |
| SD-Card |
Support Micro SD/SDHC/SDXC (up to 256G) |
| 4G/3G |
Support |
| Smart Features |
Line Crossing, Intrusion Detection, People Counting, Video Occlusion Alarm |
| Interfaces on Cable |
Audio In/Out, Alarm In/Out, RS485 |
| Network |
| Ethernet |
10M/100M Ethernet, RJ45 Port |
| Protocols |
HTTP, TCP/IP, ICMP.RTSP, RTP, UDP, RTCP, SMTP, DHCP, DNS |
| Stream |
3x Streams |
| LAN |
Support |
| User |
Up to 13 Users |
| Browser |
IE8+, Chrome18 |
| Smart Phone |
iOS/Android |
| General |
| Weight(g) |
550g |
| Material |
Front: Aluminum alloy/Black
Back: Plastic+10% fiberglass/White
|
| Working Temperature |
-20°C～60°C |
| Humidity |
Rh 10%～90% |
| Power Supply |
DC12V/1.5A |
| Waterproof |
IP67 |
